Many of you (including me) wonder about it.

Namely: Is it possible to move my ETL process from SSIS to ADF? How can I reflect current SSIS Data Flow business logic in Azure Data Factory? And turned out that new feature in ADF: Data Flow - comes with help. Furthermore, such solution will be scalable as Azure Databricks works under the hood. Don’t worry - you don’t have to know Databricks and extra language (Scala, Python) at all. How does it possible? Carry on reading.

In this post’s section, I would like to show you what kind of actions you can do and what is their equivalent in SQL and SSIS.

New world: Data Flow in Azure Data Factory

The big benefit here is that you will not write any line of code. You can design whole business logic from the scratch using Data Flow UX and appropriate code in Scala will be prepared, compile and execute in Azure Databricks behind the scenes. So that you can focus on business logic and data transformations like data cleaning, aggregation, data preparation and build code-free dataflow pipelines.

Additionally, the process would be automatically scale-out if you allow for that.

ADF Data Flow vs SSIS vs T-SQL

The main purpose of this post is to bring capabilities of (ADF) Data Flow closer and compare it to its counterparts from SSIS and relevant code of T-SQL.

Why? Because it’s far easier to understand something new by comparison to something that we know very well.

Furthermore, tables and icons talks to us much more, hence it is easy to acquire such new knowledge.

Having those fundamentals, you can re-design the current ETL process in Azure Data Factory when having a clear image of mapping components between SSIS and ADFDF. To fulfil the picture out, I have added a column that shows T-SQL code that does the same or similar things in SQL.

So, no matter which technology your current process uses, either Stored Procedures in SQL or SSIS, you are able to sit down and recreate that process to uncover new opportunities.

Components

Operation / Activity	Description	SSIS equivalent	SQL Server equivalent
New branch	Create a new flow branch with the same data	Multicast (+icon)	``` SELECT INTO
SELECT OUTPUT ```
Join	Join data from two streams based on a condition	Merge join	``` INNER/LEFT/RIGHT JOIN,
CROSS/FULL OUTER JOIN ```
Conditional Split	Route data into different streams based on conditions	Conditional Split	``` SELECT INTO WHERE condition1
SELECT INTO WHERE condition2
CASE … WHEN ```
Union	Collect data from multiple streams	Union All	``` SELECT col1a UNION (ALL)
SELECT col1b ```
Lookup	Lookup additional data from another stream	Lookup	Subselect, function, LEFT/RIGHT JOIN
Derived Column	Compute new columns based on the existing once	Derived Column	`SELECT Column1 * 1.09 as NewColumn`
Aggregate	Calculate aggregation on the stream	Aggregate	``` SELECT Year(DateOfBirth) as YearOnly,
MIN(), MAX(), AVG()
GROUP BY Year(DateOfBirth) ```
Surrogate Key	Add a surrogate key column to output stream from a specific value	Script Component	``` SELECT ROW_NUMBER()
OVER(ORDER BY name ASC) AS Row#,
name
FROM sys.databases ``` *Incremental Primary Key
(with limited capabilities)*
Exists	Check the existence of data in another stream	Lookup / Merge Join	``` SELECT * FROM Table
WHERE EXISTS(SELECT …) ```
Select	Choose columns to flow to the next stream	OUTPUT in components,
mapping columns	``` SELECT Column1, Column4
FROM Table ```
Filter	Filter rows in the stream based on a condition	Conditional Split	``` SELECT * FROM Table
WHERE [Column] LIKE ‘%pattern%’ ```
Sort	Order data in the stream based on column(s)	Sort	``` SELECT * FROM Table
ORDER BY [Column] ASC ```
Extend	Use any custom logic from an external library	Script Component	SQL CLR
Source	Source for your data flow.
Obligatory first element of every Data Flow in ADF.	OLE DB Source and more …	`SELECT * FROM SourceTable`
Sink	Destination for your data flow	OLE DB Destination and more…	`INSERT INTO TargetTable`

Update 04/01/2022

Do you think the above table is useful? Download the updated version (PDF) as a two-page cheat sheet.

More interesting materials like this can be found in the following free course: Cheat sheets for Data Engineers

Summary

This new feature has huge capabilities. I’m very excited being had opportunity to use it more.

An automatically scalable process, like this, might be very efficient with Big Data processing. Hence, it’s worth to start designing new processes with Azure Data Factory or even migrating existing processes when your enterprise suffers from performance degradation due to the amount of processing data.

Please be aware that among Microsoft solutions is another Data Flow - exists in Power BI. Do not confuse them.

In next posts of this series, I will be explaining all activities from ADF Data Flow a bit deeper.

Let me know your thoughts or leave a comment once you have any questions.

Thanks for reading!
